Stratus WCM.10.005QQ111 5-5.8GHz 3dBi SMA(M) Connector Mount Antenna with 50mm Semi-Rigid Flexiform 402 Cable

5150-5850 MHz Wi-Fi antenna
Designed for UAV / Drone Applications
Connector Mount
Right Hand Circularly Polarized
IP67 rating
Dimensions: 30.7×34.9x17mm
Cable: 50mm SS402 Coaxial Cable
Connector: RP-SMA(M)
RoHS Compliant

SKU: WCM.10.005QQ111
Request a Quote

For orders, samples and services please click on the request a quote button.

Drone Antenna for High Definition Video Streaming

The Status WCM.10 antenna is a Drone Antenna for high definition video streaming. It is an external 5150-5850MHz Drone Antenna with a high efficiency of nearly 70%? allowing it to meet the high throughput demands of drone applications, especially high definition video streams.

Circular polarization helps ensure excellent performance regardless of device orientation.

The Stratus comes in a compact size, at only 34.87*30.73*17 mm, enabling flexibility of integration. It comes with high quality, low loss, SS402 semi-rigid cable, frequently used for military and commercial aerospace applications. The cable can be bent to a fixed orientation for ease of installation.

Cable length and connector types on this antenna are customizable.

Taoglas can also customize and test antennas on your UAV in any one of our worldwide facilities subject to NRE or MOQ.

Contact your regional Taoglas sales office for support.

Additional information

Dimensions31 × 35 × 17 mm
