915MHz 5dBi Outdoors Omnidirectional Rigid Whip Antenna
Stable performance at 902 MHz to 928MHz
Omnidirectional pattern in the azimuth
Robust Weatherproof Brass Whip and Casing
N-type Male Connector
Dimensions: L:557mm Ø25mm
TI.16 915MHz 5dBi Dipole Omnidirectional Terminal Antenna, N-type Male
TI.16.5F11
TI.16.5F11
TI.16 915MHz 5dBi Dipole Omnidirectional Terminal Antenna, N-type Male
Technical Specification
| Name | Value |
|---|---|
| Technology | External Antennas, ISM/LoRA |
| Impedance | 50 |
| Minimum Operating Temperature (℃) | -40 |
| Maximum Operating Temperature (℃) | 85 |
| Mounting Style | Terminal |
| Termination Style | Connector |
| Antenna Connector Type | N Type |
| Length (mm) | 25 |
| Width (mm) | 25 |
| Height (mm) | 557 |
| Connector Body Style | Straight |
| Polarity | Linear |
| Frequency Range | 902MHz - 928MHz |
| Connector Polarity | Normal |
| Cable Length (mm) | n/a |
| VSWR | 1.5:1 |
| Weight (g) | 77 |
| RoHS | Yes |
| Gain (Max) | 1.21 |
