GA.400 – 5G/4G External Wideband Adhesive Mount Dipole Antenna covering 400-6000MHz

GA400.A.305111

Adhesive mount, ground plane independent antenna
High efficiency, high gain, wideband coverage
Covers all worldwide cellular 5G/4G between 400-6000MHz
Covers Cat-M/ LTE-M and NB-IoT bands
Low profile, IP67 rated waterproof enclosure
Cable: 3m TGC-200
Connector: SMA(M)ST
Dimensions: 360*160*20mm
RoHS & Reach Compliant

Image GA400.A.305111

GA400.A.305111

GA.400 – 5G/4G External Wideband Adhesive Mount Dipole Antenna covering 400-6000MHz

Overview

400-6000MHz 5G/4G External Mount IP67 rated, wideband adhesive mount dipole antenna

The Taoglas Guardian X GA400.A is a wideband dipole antenna that has been designed to cover all worldwide 5G and 4G bands, including all sub-6GHz deployments across the 400MHz to 6000MHz spectrum. It is designed primarily for use with 5G/4G modules and devices that require high efficiency and peak gain to deliver best in class throughput on all major cellular bands worldwide including low power bands such as Cat-M/LTE-M and NB-IoT. The GA400.A also covers extended 4G, band 71 and all 5G NR Sub 6GHz bands while also covering 3G/2G bands to allow for fallback when 5G/4G is not available.

Typical applications include:
– Passenger Bus / Rail / Air Applications.
– Automotive and Heavy Equipment Vehicle Tracking and Telematics
– Remote Asset and Pipeline Monitoring
– HD Video Streaming
– First Responder and Emergency Services

The low profile, heavy-duty, fully IP67 rated external antenna allows this antenna to be mounted in harsh external environments where a robust, waterproof antenna is required. With high peak gains and high efficiencies on frequencies from 400-6000MHz, the GA400 is a fantastic solution for wideband cellular applications.

5G applications demand high-speed data uplink and downlink. High efficiency and high gain antennas are necessary to achieve the required signal to noise ratio and throughput required to solve these challenges. Low loss TGC-200 cable is used to keep efficiency high over long cable lengths.

The cable length and connector types are customizable. Contact your regional Taoglas customer support team for more information.

Technical Specification
Name Value
Antenna Type External Antennas, Cellular
Impedance 50
Minimum Operating Temperature -40°C
Maximum Operating Temperature 85°C
Mounting Style Adhesive
Termination Style Connector
Antenna Connector Type SMA
Cable Type TGC-200
Connector Body Style Straight
Polarity RHCP
Frequency Range 400-6000MHz
Connector Polarity Normal
Cable Length (mm) 3000
Packaging Carton
VSWR 0
IP Rating IP67
RoHS Yes
Gain (Max) 3.6
Length (mm) 360
Width (mm) 160
Height (mm) 20.5
Weight (g) 550
