New Released Sep 09, 2025

4×6 Inch 8 Ohm Speaker with Integrated Wi-Fi Antenna

SPKW.46.8.01

8 Ohm Impedance
Rated Input Power 25W RMS
Max Input Power 50W Peak
Dimensions: 158x107x56mm
Antenna Connector: FAKRA Code I
Speaker Connector: DELPI 10252832
RoHS & Reach Compliant

Image SPKW.46.8.01

SPKW.46.8.01

4×6 Inch 8 Ohm Speaker with Integrated Wi-Fi Antenna

Overview

The SPKW.46.8.01 is a high-performance 4×6 inch, 8 Ohm speaker featuring an integrated high-performance Wi-Fi® antenna. As with all Taoglas audio products, the speaker is engineered to deliver clear, balanced audio output. It supports 25W RMS rated input power and up to 50W peak power handling, making it suitable for a wide range of connected audio applications. By combining reliable speaker performance with integrated antenna functionality, the SPKW.46.8.01 helps reduce system complexity, save on space and minimize additional installations, while maintaining consistent connectivity.

Designed with a compact form factor of 158 x 107 x 56 mm, the speaker is optimized for use in environments where space is limited but high-quality sound and wireless performance are required. The robust design is RoHS and REACH compliant, and the assembly includes a secure FAKRA Code I connector for ease of integration of Wi-Fi®.

Typical Applications Include:

– Smart home audio systems
– Connected kiosks and point of sale terminals
– Digital signage and public information systems
– Automotive infotainment and telematics solutions
– Industrial and commercial communication devices

The SPKW.46.8.01 provides a durable and reliable audio solution with integrated Wi-Fi® capability, ensuring reduced component count and simplified installation. Custom connector and cable options are available upon request—contact your regional support team for more information.

Technical Specification
Name Value
Power - Rated 25W
Power - Max 50W
Impedance 8
Sensitivity 88 dB Continuous @ 1m
Length (mm) 158
Width (mm) 107
Height (mm) 56
