Comet 2-in-1 – 2*5G/4G MIMO Adhesive/Magnetic Mount Puck Antenna


Low-profile Housing with Adhesive/Magnetic Mount
2* 5G/4G MIMO 600-6000MHz
Worldwide 5G Bands including legacy 4G 3G and 2G bands
IP67 Waterproof Enclosure
Dimensions: Diameter 80mm * 18.1mm
2m Low Loss TGC-1.5DS cable with SMA(M) connectors
Custom Cables and Connectors Available
RoHS & Reach Compliant

Image MA322.A.001


Comet 2-in-1 – 2*5G/4G MIMO Adhesive/Magnetic Mount Puck Antenna


Comet 2-in-1 – 2*5G/4G MIMO Adhesive/Magnetic Mount Puck Antenna

The Taoglas Comet MA322 is a low profile, puck style, adhesive/magnetic mount antenna. The MA322 contains 2 5G/4G high performance elements for use in MIMO cellular systems. It covers all cellular frequencies from 600MHz to 6GHz, which stable gain and high efficiency for an antenna of this compact size, Ø80mm x 18 mm.

The Comet series has been designed to be as compact as possible so it can be utilized in application areas where other antennas are too large. The Comet has been designed with an adhesive/magnetic mounting base, meaning it can be installed in areas where drilled a hole for securing a permanent antenna cannot be done such as leased vehicles.

Typical Applications Include:
– Telematics
– Gateways and Routers
– Digital Signage
– First Responder and Emergency Services

The IP67 waterproof ASA enclosure measures just 80x18mm excluding the 3M foam adhesive. The antenna can be mounted internally or externally on a vehicle. Both MIMO 1 and MIMO 2 coaxial cables are 2m TGC-1.5DS with SMA(M) connectors. Customized cable and connector versions are also available. Contact your regional Taoglas customer support team for further information.

Technical Specification
Name Value
Antenna Type External Antennas, Combination, Cellular
Impedance 50
Minimum Operating Temperature -40°C
Maximum Operating Temperature 85°C
Mounting Style Adhesive/Magnet
Termination Style Connector
Antenna Connector Type SMA
Cable Type TGC-1.5DS
Connector Body Style Straight
Polarity Linear
Frequency Range 617 - 5925MHz
Connector Polarity Normal
Cable Length (mm) 2000
Packaging PE Bag, Carton
IP Rating IP67
RoHS Yes
Gain (Max) 4.2
Length (mm) 79.9
Width (mm) 18.1
Height (mm) 18.1
Weight (g) 113
