No. 1 in M2M Antennas
Custom Designs
TRP/TIS/RSE Optimization

Picture from our ETS 12M 400MHz to 6GHz 3D OTA Test Chamber, Ireland

GA.110 2G/3G/4G High Gain Magnetic Mount Ultra-wideband Antenna

The GA.110 magnetic ultra-wideband cellular antenna delivers stable high omni-directional gain and efficiencies across all common 2G, 3G and 4G global cellular bands from 700 MHz to 3.5 GHz.

Technical Specifications

Wide Band High Gain Magnetic Mount Whip Antenna

698MHz to 960MHz, 1575.42MHz, 1710MHz to 2700MHz, 3500MHz

Robust High Strength Super Magnet Mount

1M RG-174 SMA(M)

Typical 40% Efficiency and 3dBi Peak Gain

Base Diameter 50mm Whip Length 298mm

View the GA.110 datasheet.
See the entire External GSM-CDMA-Cellular Magnetic Mount line.

Shockwave Wide-Band Direct Mount Antenna

The Shockwave TL.01 series is a new generation of antenna, one part number that is a highly efficient, high gain omni-directional permanent mount antenna designed for all common Cellular, Wi-Fi and ISM bands worldwide.

Technical Specifications

Shockwave Ultra-Wideband Direct Mount White

698-960/1575.42/1710-27000MHz

Worldwide Cellular 2G/3G/4G bands/GPS/ISM/Wi-Fi

IP67 Waterproof and IP69K

N Type Male Connector

View the TL.01.1F11W datasheet.
See the entire External - LTE Direct Mount line.

PA.710A Warrior Wide Band SMT Mount Antenna

The Warrior, the revolutionary patent pending PA.710A is a 2G/3G/4G, High Efficiency SMT Ceramic antenna, operating at 698MHz to 960MHz and 1710MHz to 2690MHz.

Technical Specifications

Wide-Band LTE/Cellular/CDMA SMD Antenna

LTE / GSM / CDMA / DCS / PCS / WCDMA / UMTS / HSDPA / GPRS / EDGE

698-960MHz, 1710-2690MHz

High Efficiency Wide-Band SMD Antenna

40mm*6mm*5mm

View the PA.710.A datasheet.
See the entire Internal GSM-CDMA-Cellular SMT Antennas line.

MA.750 5in1 Pantheon 2 x 2G/3G/4G MIMO: GPS: 2 x Wi-Fi MIMO

We have packed 5 high efficiency and gain antennas in an extremely robust IP67 direct mount antenna package with excellent isolation (20dB+). The antenna has its own ground-plane and can radiate on any mounting environment like metal or plastic without affecting performance. The cables are low loss allowing for lengths of up to 10 meters, critical for buses, trains and other commercial transport applications.

Technical Specifications

Pantheon - 2G/3G/4G MIMO~GPS~2.4/5GHz MIMO

GPS - 1575MHz -3M RG-174 SMA(M) 50% Efficiency

2 x 2G/3G/4G MIMO Antenna (698~960MHz,1710~2170MHz,2300~2700MHz,2900~3500MHz)

2 x Wi-Fi/Public Safety/Zigbee 2.4/4.9~6GHz

Diameter 145.79mm * Height(profile) 85.73mm

View the MA750.A.ABICG.003 datasheet.
See the entire External Combination 5in1 Pantheon line.

Ulysses Ultra-Low Profile Miniature GPS and Glonass Antenna

The Ulysses miniature super low profile (only 10mm in height) GNSS antenna is designed for applications which require high positioning accuracy by combining signals from GPS and GLONASS systems. A high gain wide-band patch antenna on an integral ground delivers reliable performance.

Technical Specifications

Ulysses Ultra-Low Profile Miniature GPS and Glonass Antenna

High Gain 1575-1610MHz

3M RG-174 SMA(M)

Magnetic Mount

40.4*37.8*10mm

View the AA.162.301111 datasheet.
See the entire External GPS - Magnetic Mount line.

DTAD.01.A.50 Digital Tunable Antenna Reference Design

The DTAD.01.A.50 is an evaluation board for Taoglas new patent pending series of Evolution DTA tunable antennas. DTA antennas deliver higher efficiency on smaller ground-plane than traditional passive antennas, enabling a new miniaturized generation of high performance wireless devices.

Technical Specifications

Compact Evaluation Board for Evolution DTA.01.A Digital Tunable Antenna

698-960/1710-2170MHz worldwide cellular 3G/4G bands

Complete Reference Design

Increases antenna efficiency from ~7% to ~28%

USB Interface, SMA(F) connector for antenna measurement

View the DTAD.01.A.50 datasheet.
See the entire Internal - LTE Digital Tunable Antennas line.

Olympian - Wide Band Screw Mount Antenna

The G.30 Olympian is a high performance screw mount wide-band cellular antenna for external use on vehicles and outdoor assets worldwide. Omni-directional high gain and high efficiency across all bands ensures constant reception and transmission. This is vital for today's high data bandwidth applications in video and mobile broadband.

Technical Specifications

SMA(M) - 1M RG-316 IP67

LTE/GSM/CDMA/DCS/PCS/WCDMA/UMTS/

HSDPA/GPRS/EDGE/IMT

698~960MHz & 1710~2700MHz

Diameter - 50mm(1.97”) Profile Height 48mm(1.89”)

View the G30.B.108111 datasheet.
See the entire External GSM-CDMA-Cellular Screwmount line.

The Cloud FXP611 GPS/GLONASS/COMPASS Flexible Loop Antenna

High Efficiency at 80% and 3dBi Gain, coupled with Unique Detuning Design Brings OEM Advantages to The Cloud FXP.611 GPS/Glonass/COMPASS Flexible Loop Antenna

Technical Specifications

The Cloud GNSS Flexible Loop Antenna

GPS-GLONASS-COMPASS

1559-1610MHz

3dBi Peak Gain - 80% Efficiency

Dims: 38mm*37mm*0.15mm

*Patent Pending*

View the FXP611.07.0092C datasheet.
See the entire Internal GPS-GLONASS-GNSS Flexible Loop Antenna line.

ISA.01 400-470MHz Wide-band Omni-directional Low Profile Adhesive Glass Mount Antenna

The ISA.01 and ISA.06 are Omni-directional wide-band low profile 400MHz to 470MHz antennas for internal or external applications adhesive mounted on glass(ISA.01) or plastic(ISA.06).
